Ecorend MR1 25kg White Pearl

PACK SIZE
25kg Bag

FINISHING TOOL
Scrape Float

SUBSTRATE PRIMER
S10 or K11 (Dependent on substrate)

SUITABLE SUBSTRATE
Concrete, Clay, Lightweight Block and Brick Pot Life 1 Hour + Water Demand Approx. 4.5 - 5 litres per 25kg bag Ready to Finish 3-16 hours @ 5˚C - 25˚C

DESCRIPTION
Ecorend MR1 Monocouche One Coat Render, is a high performance, cement based, through coloured scratch render. Developed to have excellent water repellence, breathability and adhesion, it is also easy to apply, by hand or by spray, in one coat. The products through colour characteristics ensure a low maintenance, attractive, stone looking finish.

PREPARATION
All surfaces must be sound, clean, dry and free of any material which may impair adhesion. Do not apply to shiny surfaces. Scaffolding must be independently tied to allow for uninterrupted application. Any faults in the structure, particularly those which may lead to moisture penetration, must be rectified. Mask around the areas where material is to be applied. Masking tape must be removed before the material has dried out. Beads and expansion joints should be included as required by the substrate and BS standards and carried through all applied materials.

PRIMING
When applying to concrete block, prime with Ecorend S10 Bonding Primer When applying to clay, lightweight block and brick, prime with Ecorend K11 Key Coat Primer MIXING Ecorend MR1 Monocouche One Coat Render should be mixed with clean water at a rate of approximately 4.5 - 5.0 litres per 25kg bag using a suitable paddle or pan mixer. Mix for 2 minutes, allow to stand for 2 minutes then re-mix. This process allows the additives to dissolve and activate.

APPLICATION
To avoid dampness and discolouration rendering should be avoided below DPC or within 150mm of ground level. Ecorend MR1 Monocouche One Coat Render should be applied in a one-coat 2 pass operation to 17mm and finished to 15mm thick. The 1st pass should be applied to the primed substrate with a stainless steel trowel or spray pump, and for ease of application a serrated feather edge and finishing spatula will help. Apply the 1st pass to approx. 8mm thick with fibre-reinforcing mesh included in the 1st pass ensuring that the mesh is overlapped 100mm at the mesh joints. Additional fibre-reinforcing mesh stress patches of 500 x 500 mm should be added at all openings i.e. windows and doors, and also window reveals for additional substrate stress protection. The 2nd pass should then be applied to approx. 9mm thick, wet on wet to the 1st pass and levelled flat. Then leave the render to harden but not fully set for between 3-16 hours dependent on the temperature. This will allow the surface to harden, ready to finish once you can imprint your nail but not your thumb print, at this point the render is ready to scrape. Scraping should take place using a scraping float, scrape the surface in a tight circular action. It is essential that this operation is done carefully and evenly, the objective is to only remove 2mm from the complete surface. During the operation of scraping the render, use a straight edge to ensure any high spots are evened out. Immediately following the scraping process (preferably use a second man for this process), use a light soft brush to remove all loose material. Carrying out this process may highlight any un-scraped areas. Un-scraped areas must be scraped immediately to avoid colour variation that will occur if scraped when the product has started to set. Small blemishes or holes can be repaired at this stage by using material freshly scraped from the wall and pointed in. Once the product is fully scraped the minimum finish thickness should be 15mm. Specification Clauses relating to this product can be found in NBS Section M20 Rendering. BS 5262 Code of Practice for External Rendering and BS 8000-10 must be followed.

MR1 adheres to a range of correctly prepared masonry substrates. The required primer depends on the background: S10 Bonding Primer is used on suitable concrete block, while K11 Key Coat Primer is specified for clay, brick and lightweight block.

Application information:

• Mix with approximately 4.5–5 litres of clean water per bag
• Allow around one hour of working time
• Apply in two wet-on-wet passes
• Build up to approximately 17mm
• Leave for around 3–16 hours before scraping
• Remove approximately 2mm with a scrape float
• Maintain a finished thickness of 15mm
• Apply by stainless-steel trowel or suitable spray pump

Product specification:

• Shade: White Pearl
• Product type: Through-coloured monocouche render
• Finish: Scraped, natural stone effect
• Suitable substrates: Concrete, clay, brick and lightweight block
• Water absorption classification: W2
• Pack size: 25kg

Use bags from the same production batch across each continuous elevation and maintain consistent water quantities, mixing times and scraping conditions to minimise visible colour variation.
